Air Conditioning Unit Design
This air conditioning design features a wall-mounted unit optimized for efficient cooling. The design is suitable for both residential and commercial environments.
Technical Specifications
Service Overview
Comprehensive Appliance Development
This service provides a full-cycle solution for air conditioning unit development, covering the entire value chain from initial market research to final pilot production. The process includes industrial and technical design, functional prototyping, mold manufacturing, and process documentation. Clients receive end-to-end support including CKD supply, quality control, and assembly process training to ensure seamless manufacturing integration.
Development Lifecycle
- Customer Demand & Market Analysis
- Industrial Design Proposal
- Technical & Cooling System Design
- Functional Prototype Manufacture
- Mold Design & Manufacturing
- Process Documentation
- Standard Prototype Testing
- CKD Supply & Quality Control
- Pilot Production & Technical Support
Technical Specifications
Capacity and Efficiency Metrics
| Model | Capacity (W) | Prototype Efficiency | Pilot Efficiency | Mass Prod. Efficiency |
|---|---|---|---|---|
| 12K (Fixed) | 3517 | >=3.69 | >=3.69 | >=3.55 |
| 18K (Fixed) | 5275 | >=3.69 | >=3.69 | >=3.55 |
| 22K (Fixed) | 6448 | >=3.69 | >=3.69 | >=3.55 |
| 12K-3* (Inverter) | 3517 | >=3.69 | >=3.69 | >=3.55 |
| 18K-3* (Inverter) | 5275 | >=3.69 | >=3.69 | >=3.55 |
| 22K-3* (Inverter) | 6448 | >=3.69 | >=3.69 | >=3.55 |
| 12K-5* (Inverter) | 3517 | >=4.69 | >=4.69 | >=4.55 |
| 18K-5* (Inverter) | 5275 | >=4.69 | >=4.69 | >=4.55 |
