6-Cavity Automatic Bottle Blowing Machine
This 6-cavity automatic bottle blowing machine is designed for high-volume production. It features automated preform loading, bottle ejection, and precise temperature control to ensure consistent bottle quality for various applications.
Technical Specifications
Overview
High-Efficiency Automatic Blowing Technology
This advanced 6-cavity linear blow molding machine utilizes cutting-edge technology to deliver high-speed, fully automatic production of PET bottles. Designed for optimal efficiency, the system features a specialized heating furnace that reduces energy consumption by 40% compared to standard models. With integrated automatic detection and fault monitoring, this machine ensures stable, consistent output while significantly minimizing operator intervention and safety risks.
Production Metrics
Theoretical Output
9,000 Pcs/H
Max Output
Production Details
| Metric | Value |
|---|---|
| Cavities | 6 |
| Volume Range | 0.1 - 2 L |
| Max Bottle Height | 320 mm |
| Max Bottle Diameter | 115 mm |
Technical Specifications
Power Requirements
- Total Power: 48 KW
- Heating Power: 36 KW
Air System Specifications
- Operation Pressure: 0.8 Mpa
- Action Air Consuming: 3.0 M3/Min
- Blowing Air Consuming: 3.0 M3/Min
Moulding Parameters
- Mould Thickness: 200 mm
- Mould Opening Stroke: 220 mm
Key Features
System Advantages
40% Energy SavingFully AutomaticFault DetectionAutomatic AlarmHigh Stability
- Compatible Materials
- PET
Physical Dimensions
Machine Dimensions
| Component | Dimensions (L*W*H) | Weight |
|---|---|---|
| Main Body | 4.85 * 1.8 * 2.3 M | 4800 KG |
| Preform Autoloader | 2.15 * 1.5 * 2.7 M | 800 KG |
