500L-1000L Oil Refining Machine
This industrial oil refinery machine processes oil in batches from 500L to 1000L. It features a multi-stage filtration and refining system with a stainless steel construction.
Technical Specifications
Overview
Professional Oil Refining System
This compact edible oil refinery is engineered for small to medium-scale operations, providing a comprehensive solution for degumming, deacidification, dehydration, and decolorizing crude oil. The system integrates a refining tank, decolorizing tank, hot water tank, and an oil pump into a single, mobile unit mounted on wheels. Equipped with an electric control cabinet and automatic temperature control, it ensures precise processing and consistent oil quality.
Performance Metrics
Refining Tank Capacity
250 L
Working Capacity
- Processing Functions
- DegummingDeacidificationDehydrationDecolorizing
Technical Specifications
Component Specifications
| Item | Model | Power | Working Cubage |
|---|---|---|---|
| Oil refining tank | DN700*1300 | 12/0.55 kW | 250 |
| Decolorizing tank | DN630*1100 | 6 kW | 300 |
| Hot water tank | DN320*600 | 6 kW | 25 |
| Oil pump | - | 0.37 kW | 1 |
- Decolorizing Efficiency
- 5 H/tank
Features
Key Features
- Automatic temperature control system
- Thermal insulation device
- Integrated feeding buffer sets
- Mobile design with wheeled frame
- Stainless steel construction
