304 Stainless Steel V-Profile Wedge Wire Screen
The 304 Stainless Steel V-Profile Wedge Wire Screen is composed of V-wires and longitudinal support rods. Fusion welding at each wire intersection provides sturdy construction and good mechanical properties.
Technical Specifications
Product Overview
High-Performance Filtration
The 304 Stainless Steel V-Profile Wedge Wire Screen is engineered for superior filtration and separation efficiency. Featuring fusion-welded construction at every wire intersection, it provides exceptional mechanical strength and durability. Its unique V-shaped profile effectively prevents clogging and ensures optimal, unimpeded fluid flow even under high-pressure conditions.
Technical Specifications
Wire and Rod Dimensions
| Component | Option A (W x H) | Option B (W x H) |
|---|---|---|
| Screen Wire | 3 x 4.6mm | 3 x 5.4mm |
| Support Rod | 3 x 4.6mm | 3 x 5.4mm |
- Material Composition
- Stainless Steel AISI 304
- Outer Diameter
- 178 mm
- Slot Size
- 0.5 mm
- Length
- 5.8 m
- Number of Support Rods
- 34
Shipping and Handling
- Packaging Options
- Woven BagsBubble BagsWooden StripsWooden Cases
