10-Inch Stainless Steel Well Screen with Wedge Wire
This 10-inch stainless steel well screen utilizes a wedge wire design for efficient water filtration. Its construction ensures corrosion resistance and optimal water flow, making it suitable for various well applications.
Technical Specifications
Product Overview
High-Efficiency Wedge Wire Well Screen
This 10-inch stainless steel well screen is engineered for superior water filtration and durability in demanding well environments. Featuring a continuous V-shaped slot design, it maximizes open area to enhance water intake efficiency while significantly reducing frictional head loss. Constructed from corrosion-resistant stainless steel, this screen provides reliable sand control, extends pump life, and offers substantial energy savings for water extraction systems.
Technical Specifications
Standard Lengths
- 1m
- 5.85m
Connection Styles
WeldingThreaded Male/Female Coupling
- Material Grades
- 302304304L316316L
- Nominal Diameter
- 10 inch
- Minimum Slot Size
- 0.05 mm
Performance Metrics
Key Performance Indicators
25 %
Power Savings
2 x
Efficiency Increase
Design Features
Design Advantages
- Continuous V-shaped slot design prevents clogging
- High open area percentage for maximum flow
- Corrosion and heat resistant construction
- Wide range of slot sizes available (from 0.15mm)
