1-3kVA Online UPS with Lithium Battery
This high-frequency online UPS uses double conversion technology. It features digital signal processor (DSP) control.
Technical Specifications
Overview
High-Performance Lithium-Powered UPS
This 1-3kVA online double-conversion UPS is engineered for critical applications requiring continuous, stable power. By utilizing advanced lithium battery technology, the system offers superior energy density, a long cycle life of over 2000 cycles, and excellent performance across temperature ranges. It features intelligent monitoring, wide input voltage tolerance, and flexible communication options, making it an ideal solution for protecting sensitive servers and networking equipment.
Electrical Performance
Power Capacity
1 kVA
Minimum Capacity
3 kVA
Maximum Capacity
Power Factor
0.99
Input Power Factor
0.9
Output Power Factor
- Input Voltage Range
- 110 - 300 Vac
- Frequency Range
- 40 - 70 Hz
Battery System
Battery Technology
Lithium Battery
- Cycle Life
- ≥ 2000 cycle times
- Autonomy at Full Load
- 15 min
Key Features
Communication Interfaces
- RS232 (Standard)
- USB (Optional)
- RS485 (Optional)
- SNMP (Optional)
- Dry Contacts (Optional)
Settable Modes
- Bypass Mode
- ECO Mode
- Frequency Conversion Mode
- Core Technologies
- Online Double ConversionDSP ControlActive Power Factor CorrectionAuto-Sensing Frequency
