1-3KVA 110V High Frequency Online UPS Power Supply
This online double conversion UPS offers a wide input voltage range. Tower and rackmount configurations are available with optional USB/SNMP adapter, dry contact, and EPO.
Technical Specifications
Product Overview
High-Frequency Online UPS Solutions
This 1-3KVA Online Double Conversion UPS provides high-reliability power protection for sensitive electronic equipment. Designed for 110V systems, it features a wide input voltage range and high performance to ensure stable operation in demanding environments. With flexible tower or rackmount configurations and multiple communication options, it is an ideal choice for critical infrastructure.
Core Performance
Key Performance Metrics
0.99 Full Load
Power Factor
110 Vac
Rated Voltage
70 Hz
Max Frequency
Technical Specifications
Model Capacity & Structure
| Model Series | Capacity | Structure |
|---|---|---|
| AW1KS/L | 1000VA | Tower |
| AW2KS/L | 2000VA | Tower |
| AW3KS/L | 3000VA | Tower |
| RAW1KS/L | 1000VA | Rackmount |
| RAW2KS/L | 2000VA | Rackmount |
| RAW3KS/L | 3000VA | Rackmount |
Input Features
- Supported Voltages
- 110Vac115Vac120Vac127Vac
- Phase
- Single phase
- Frequency Range
- 40-70Hz
Battery System
Battery Voltage Options
- 24Vdc
- 36Vdc
- 48Vdc
- 72Vdc
- 96Vdc
Connectivity & Options
Communication Ports
- RS232 (Standard)
- USB (Optional)
- SNMP Adapter (Optional)
- Dry Contact (Optional)
- EPO (Optional)
Applications
Ideal For
Data Center19” Rack DevicesCommercial FacilitiesTelecom SystemsIT RoomsPrecision Instruments
Compliance & Quality
- Standards & Compliance
- CEISO 9001ISO 14001ISO 45001TLC
